ANSI Inch Adjustable Ring Gauges

Series 695
ANSI Inch Adjustable Ring Gauges
  • ANSI Inch Adjustable Ring Gauges

FEATURES

  • ANSI standard
Inquiry

PRODUCT SPECIFICATIONS

INCH METRIC
SizeCode No.
0 - 80UNF 695-01-5
1 - 64UNC 695-02-5
1 - 72UNF 695-03-5
2 - 56UNC 695-04-5
2 - 64UNF 695-05-5
3 - 48UNC 695-06-5
3 - 56UNF 695-07-5
4 - 40UNC 695-08-5
4 - 48UNF 695-09-5
5 - 40UNC 695-10-5
5 - 44UNF 695-11-5
6 - 32UNC 695-12-5
6 - 40UNF 695-13-5
8 - 32UNC 695-14-5
8 - 36UNF 695-15-5
10 - 24UNC 695-16-5
10 - 32UNF 695-17-5
12 - 24UNC 695-18-5
12 - 28UNF 695-19-5
1/4 - 20UNC 695-20-5
1/4 - 28UNF 695-21-5
1/4 - 32UNEF 695-22-5
5/16 - 18UNC 695-23-5
5/16 - 24UNF 695-24-5
5/16 - 32UNEF 695-25-5
3/8 - 16UNC 695-26-5
3/8 - 24UNF 695-27-5
3/8 - 32UNEF 695-28-5
7/16 - 14UNC 695-29-5
7/16 - 20UNF 695-30-5
7/16 - 28UNEF 695-31-5
1/2 - 13UNC 695-32-5
1/2 - 20UNF 695-33-5
1/2 - 28UNEF 695-34-5
9/16 - 12UNC 695-35-5
9/16 - 18UNF 695-36-5
9/16 - 24UNEF 695-37-5
5/8 - 11UNC 695-38-5
5/8 - 18UNF 695-389-5
5/8 - 24UNEF 695-40-5
3/4 - 10UNC 695-41-5
3/4 - 16UNF 695-42-5
3/4 - 20UNEF 695-43-5
7/8 - 9UNC 695-44-5
7/8 - 14UNF 695-45-5
7/8 - 20UNEF 695-46-5
1" - 8UNC 695-47-5
1" - 12UNF 695-48-5
SizeCode No.
0 - 80UNF 695-01-4
1 - 64UNC 695-02-4
1 - 72UNF 695-03-4
2 - 56UNC 695-04-4
2 - 64UNF 695-05-4
3 - 48UNC 695-06-4
3 - 56UNF 695-07-4
4 - 40UNC 695-08-4
4 - 48UNF 695-09-4
5 - 40UNC 695-10-4
5 - 44UNF 695-11-4
6 - 32UNC 695-12-4
6 - 40UNF 695-13-4
8 - 32UNC 695-14-4
8 - 36UNF 695-15-4
10 - 24UNC 695-16-4
10 - 32UNF 695-17-4
12 - 24UNC 695-18-4
12 - 28UNF 695-19-4
1/4 - 20UNC 695-20-4
1/4 - 28UNF 695-21-4
1/4 - 32UNEF 695-22-4
5/16 - 18UNC 695-23-4
5/16 - 24UNF 695-24-4
5/16 - 32UNEF 695-25-4
3/8 - 16UNC 695-26-4
3/8 - 24UNF 695-27-4
3/8 - 32UNEF 695-28-4
7/16 - 14UNC 695-29-4
7/16 - 20UNF 695-30-4
7/16 - 28UNEF 695-31-4
1/2 - 13UNC 695-32-4
1/2 - 20UNF 695-33-4
1/2 - 28UNEF 695-34-4
9/16 - 12UNC 695-35-4
9/16 - 18UNF 695-36-4
9/16 - 24UNEF 695-37-4
5/8 - 11UNC 695-38-4
5/8 - 18UNF 695-389-4
5/8 - 24UNEF 695-40-4
3/4 - 10UNC 695-41-4
3/4 - 16UNF 695-42-4
3/4 - 20UNEF 695-43-4
7/8 - 9UNC 695-44-4
7/8 - 14UNF 695-45-4
7/8 - 20UNEF 695-46-4
1" - 8UNC 695-47-4
1" - 12UNF 695-48-4
