| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-.6" | ± .0001" | .001" | Φ0.197" | W/O | Flat | W/O | 169-15-1 | |
| 0-.6" | ± .0001" | .001" | Φ0.197" | W/O | Spherical | W/O | 169-15-3 | |
| 0-.6" | ± .0001" | .001" | Φ0.197" | W/O | Flat | With | 169-15-5 | |
| 0-.6" | ± .0001" | .001" | Φ0.197" | W/O | Spherical | With | 169-15-7 | |
| 0-.6" | ± .0001" | .001" | Φ0.197" | With | Flat | W/O | 169-25-1 | |
| 0-.6" | ± .0001" | .001" | Φ0.197" | With | Spherical | W/O | 169-25-3 | |
| 0-.6" | ± .0001" | .001" | Φ0.197" | With | Flat | With | 169-25-5 | |
| 0-.6" | ± .0001" | .001" | Φ0.197" | With | Spherical | With | 169-25-7 | |
| 0-.6" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-35-1 | |
| 0-.6" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-35-3 | |
| 0-.6" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | With | 169-35-5 | |
| 0-.6" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | With | 169-35-7 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-21-1 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-21-3 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Flat | W/O | 169-31-1 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Spherical | W/O | 169-32-1 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-31-3 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-32-3 | |
| 0-1" | ± .0001" | .0001" | Φ0.256" | W/O | Carbide & Flat | W/O | 169-31-5 | |
| 0-1" | ± .0001" | .0001" | Φ0.256" | W/O | Carbide & Spherical | W/O | 169-32-5 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-31-7 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-32-7 |
| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | W/O | Flat | W/O | 169-15-0 | |
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | W/O | Spherical | W/O | 169-15-2 | |
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | W/O | Flat | With | 169-15-4 | |
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | W/O | Spherical | With | 169-15-6 | |
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | With | Flat | W/O | 169-25-0 | |
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | With | Spherical | W/O | 169-25-2 | |
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | With | Flat | With | 169-25-4 | |
| 0-15mm | 0.004mm | 0.01mm | Φ5mm | With | Spherical | With | 169-25-6 | |
| 0-15mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-35-0 | |
| 0-15mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-35-2 | |
| 0-15mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | With | 169-35-4 | |
| 0-15mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | With | 169-35-6 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-21-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-21-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Flat | W/O | 169-31-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Spherical | W/O | 169-32-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-31-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-32-2 | |
| 0-25mm | 0.004mm | 0.002mm | Φ6.5mm | W/O | Carbide & Flat | W/O | 169-31-4 | |
| 0-25mm | 0.004mm | 0.002mm | Φ6.5mm | W/O | Carbide & Spherical | W/O | 169-32-4 | |
| 0-25mm | 0.004mm | 0.002mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-31-6 | |
| 0-25mm | 0.004mm | 0.002mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-32-6 |
