| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-1" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Flat | W/O | 169-11-3 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Spherical | W/O | 169-11-1 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Flat | With | 169-01-3 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | W/O | Carbide & Spherical | With | 169-01-1 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | With | Carbide & Flat | W/O | 169-41-1 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | With | Carbide & Spherical | W/O | 169-41-3 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | With | Carbide & Flat | With | 169-42-1 | |
| 0-1" | ± .0001" | .001" | Φ0.256" | With | Carbide & Spherical | With | 169-42-3 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-51-1 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-52-1 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-53-1 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-54-1 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-51-3 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-52-3 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Flat | W/O | 169-53-3 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Spherical | W/O | 169-54-3 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | With | 169-51-5 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | With | 169-52-5 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Flat | With | 169-53-5 | |
| 0-1" | ± .0001" | .001" | Φ0.315" | W/O | Carbide & Spherical | With | 169-54-5 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Flat | With | 169-51-7 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Spherical | With | 169-52-7 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Flat | With | 169-53-7 | |
| 0-1" | ± .0001" | .0001" | Φ0.315" | W/O | Carbide & Spherical | With | 169-54-7 |
| Range | Accuracy | Graduation | Spindle Dia. | Spindle Lock | Measuring Face | Clamp Nut | Code No. | |
|---|---|---|---|---|---|---|---|---|
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Flat | W/O | 169-11-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Spherical | W/O | 169-11-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Flat | With | 169-01-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | W/O | Carbide & Spherical | With | 169-01-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | With | Carbide & Flat | W/O | 169-41-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | With | Carbide & Spherical | W/O | 169-41-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | With | Carbide & Flat | With | 169-42-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ6.5mm | With | Carbide & Spherical | With | 169-42-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-51-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-52-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-53-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-54-0 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-51-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-52-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | W/O | 169-53-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | W/O | 169-54-2 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | With | 169-51-4 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | With | 169-52-4 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | With | 169-53-4 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | With | 169-54-4 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | With | 169-51-76 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | With | 169-52-6 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Flat | With | 169-53-6 | |
| 0-25mm | 0.004mm | 0.01mm | Φ8mm | W/O | Carbide & Spherical | With | 169-54-6 |
