| Range | Individual Range | Setting Ring | Extension Rod | Code No. | |
|---|---|---|---|---|---|
| .08-.12" (2pcs) |
0.08-0.1" 0.1-0.12" |
0.1" | - | 208-61-9 | |
| .12-.28" (4 pcs) |
0.12-0.16" 0.16"-0.2" 0.2-0.24" 0.24-0.28" |
0.16" 0.24" |
- | 208-62-9 | |
| .275-.5" (3 pcs) |
0.275-0.35" 0.35-0.425" 0.425"-0.5" |
0.275" 0.35" 0.5" |
4" | 208-63-9 | |
| .5-.8" (2pcs) |
0.5-0.65" 0.65-0.8" |
0.65" | 6" | 208-64-9 | |
| .8-2" (4 pcs) |
0.8-1" 1-1.2" 1.2-1.6" 1.6-2" |
0.11" 1.6"" |
6" | 208-65-9 | |
| 2-4" (4 pcs) |
2-2.5" 2.5-3" 3-3.5" 3.5-4" |
2.5" 3.5" |
6" | 208-66-9 |
| Range | Individual Range | Setting Ring | Extension Rod | Code No. | |
|---|---|---|---|---|---|
| 2-3mm (2pcs) |
2-2.5mm 2.5-3mm |
2.5mm | - | 208-61-8 | |
| 3-6mm (3 pcs) |
3-4mm 4-5mm 5-6mm |
4mm 5mm 6mm |
- | 208-62-8 | |
| 6-12mm (3 pcs) |
6-8mm 8-10mm 10-12mm |
6mm 8mm 10mm |
100mm | 208-63-8 | |
| 12-20mm (2pcs) |
12-16mm 16-20mm |
16mm | 150mm | 208-64-8 | |
| 20-50mm (4 pcs) |
20-25mm 25-30mm 30-40mm 40-50mm |
25mm 40mm |
150mm | 208-65-8 | |
| 50-100mm (4 pcs) |
50-63mm 62-75mm 75-88mm 87-100mm |
62mm 87mm |
150mm | 208-66-8 |
| Range | Individual Range | Setting Ring | Extension Rod | Code No. | |
|---|---|---|---|---|---|
| .08-.12" (2pcs) |
0.08-0.1" 0.1-0.12" |
0.1" | - | 209-61-9 | |
| .12-.28" (4pcs) |
0.12-0.16" 0.16"-0.2" 0.2-0.24" 0.24-0.28" |
0.16" 0.24" |
- | 209-62-9 | |
| .275-.5" (3pcs) |
0.275-0.35" 0.35-0.425" 0.425"-0.5" |
0.275" 0.35" 0.5" |
4" | 209-63-9 | |
| .5-.8" (2pcs) |
0.5-0.65" 0.65-0.8" |
0.65" | 6" | 209-64-9 | |
| .8-2" (4pcs) |
0.8-1" 1-1.2" 1.2-1.6" 1.6-2" |
0.11" 1.6" |
6" | 209-65-9 | |
| 2-4" (4pcs) |
2-2.5" 2.5-3" 3-3.5" 3.5-4" |
2.5" 3.5" |
6" | 209-66-9 |
| Range | Individual Range | Setting Ring | Extension Rod | Code No. | |
|---|---|---|---|---|---|
| 2-3mm (2pcs) |
2-2.5mm 2.5-3mm |
2.5mm | - | 209-61-8 | |
| 3-6mm (3pcs) |
3-4mm 4-5mm 5-6mm |
4mm 5mm 6mm |
- | 209-62-8 | |
| 6-12mm (3pcs) |
6-8mm 8-10mm 10-12mm |
6mm 8mm 10mm |
100mm | 209-63-8 | |
| 12-20mm (2pcs) |
12-16mm 16-20mm |
16mm | 150mm | 209-64-8 | |
| 20-50mm (4pcs) |
20-25mm 25-30mm 30-40mm 40-50mm |
25mm 40mm |
150mm | 209-65-8 | |
| 50-100mm (4pcs) |
50-63mm 62-75mm 75-88mm 87-100mm |
62mm 87mm |
150mm | 209-66-8 |
